TeTe Motor
TeTe Motor
| MODEL | VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | STALL | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| OPERATING RANGE (V) | NOMINAL | SPEED | CURRENT | SPEED | CURRENT | TORQUE | OUTPUT | TORQUE | CURRENT | ||||
| V | r/min | A | r/min | A | mN.m | g.cm | W | mN.m | g.cm | A | |||
| TRS-550PM | 35100 | 3.0 - 18.0 | 12.0 | 5200 | 0.25 | 4330 | 1.60 | 29.41 | 300 | 13.3 | 176.47 | 1800 | 8.32 |
| 6530 | 6.0 - 12.0 | 12.0 | 18000 | 1.30 | 16100 | 7.15 | 41.18 | 420 | 69.0 | 344.31 | 3512 | 52.0 | |
The operating voltage range depends on the configuration: Model 35100 operates between 3.0V and 18.0V (nominal 12.0V), while Model 6530 operates between 6.0V and 12.0V (nominal 12.0V).
Under nominal load, the 6530 variation can reach a high speed of up to 18,000 RPM, making it suitable for applications requiring rapid rotation.
This motor is designed with several performance advantages: it operates under low current, maintains low noise levels, produces no sparks during operation, and offers vibration-free performance.
It is commonly integrated into high-demand equipment and toys, including ride-on toys, grass trimmers, portable air compressors, and power drills.
The motor can achieve a stall torque of up to 3512 g.cm (344.31 mN.m) under full stall conditions for the 6530 specification.
At peak efficiency, the motor balances output and power consumption perfectly, delivering speeds of 4330 RPM or 16,100 RPM depending on the chosen model variation.
