TeTe Motor
TeTe Motor
| Motor Model | Specifications (Part 1) | Specifications (Part 2) |
|---|---|---|
| GM12-15BY-30 | Rated voltage: 5VDC | Resistance: 10Ω |
| No. of Phase: 2 | Holding Torque: 500g.cm | |
| Step Angle: 18° | Current: 500mA | |
| Gear Ratio: 1/30 | Pull in Rate: 800pps | |
| GM12-15BY-50 | Rated voltage: 5VDC | Resistance: 10Ω |
| No. of Phase: 2 | Holding Torque: 700g.cm | |
| Step Angle: 18° | Current: 500mA | |
| Gear Ratio: 1/50 | Pull in Rate: 850pps | |
| GM12-15BY-110 | Rated voltage: 5VDC | Resistance: 10Ω |
| No. of Phase: 2 | Holding Torque: 1050g.cm | |
| Step Angle: 18° | Current: 500mA | |
| Gear Ratio: 1/110 | Pull in Rate: 850pps |
Automatic door operators, automatic energy saving bath, electrical controlled valve, robots, grass cutter, electric curtain, camera, medical service, oxygen machine, etc.
| Industry | Applications | |||
|---|---|---|---|---|
| Business Machines | Vending Machines | Printers | ATM | Copiers and Scanners |
| Camera and Optical | Video | Cameras | Projectors | - |
| Lawn and Garden | Lawn Mowers | Snow Blowers | Trimmers | Leaf Blowers |
ISO9001, SGS, National high-tech enterprises, etc.
We have been specializing in micro motors, gear motors and their respective parts since 2000. Our products are widely used in entertainment systems, automobiles, home and industrial appliances, tools, and many other fields. Designed for dependability and long-lasting performance, our products are backed by years of manufacturing expertise. We export 98% of our output worldwide, leveraging a reputation for quality and reliability.
NIKE, FLEXTRONICS, STANLEY, etc.
Standard packing
"Excellent quality, better price, good service, and on-time delivery."
